UPVC double pipe production line
1. Features of UPVC double pipe extrusion line:
The products produced by the UPVC double-pipe extrusion production line are mainly used in construction threading pipes, electrical pipes, etc. The first-class quality has been integrated into many years of experience. The main machine adopts a conical twin-screw extruder to improve the mixing effect and the extrusion pressure is high.?Double tube extrusion die.?High production efficiency and stable molding.?Using double-tube vacuum sizing technology, spray cooling to ensure the quality of the tube.?Independent control of the overall structure of the double-tube pulling mechanism and synchronous cutting device.?The equipment is compact and occupies a small area.
2. Main technical parameters:
| model | SJSZ51/105 |
| Applicable raw materials | pvc |
| Extruder Model | SJSZ51/105 |
| Diameter range mm | 16-50 |
| Motor Power | 22kw |
| Maximum extrusion volume | 120kg/h |
| Production speedm/min | 3-10 |
